Eyepiece Magnification | 12.5× |
Objective Lens | f=200 |
Working Distance | 190mm |
Magnifications for Main Microscope | 5.3×,8×,12× |
Diameter of Field | F37mm,F25mm,F16.7mm |
Diopter Adjustment | ±7D |
Pupil Distance | 50mm~80mm |
Maximal Resolution | 100LP/mm |
Illumination Source | 12V/100W,medical cold reflection halogen lamp |
Illumination Type | 6°+0°Coaxial cold light source illumination |
Coaxial Illumination | ≥30000lx |
Reaching Radius of Arm | 870mm |
Adjustable Vertical Range | 700mm~1100mm |
Fine Focusing Range | 30mm |
Input Voltage | AC220V±22 V / 50Hz±1Hz,AC110V±11V /60Hz±1Hz |
Power | 120VA |
Fuse | AC250V T1.25A ,AC125V T2.5A |
Electrical Safety Standard | Executive Standard: GB9706.1-2007,type I |
Packing Volume | 0.2m3,1carton |
Total Weight | 41kg |
