Features :
• 14mm aperture provides broader and clearer field of view.
• Joystick is made by metal, and the overall appearance is fantastic, and at the same time it increases clinical operation space.
•Five-step drum magnification of eyepiece. Sclera vein could be ocserved under the 40X magnification.
• All the joints can be connected by accessories with with international standards.
• By stepless adjustable photoelectric box, it can provide all kinds of appropriate brightness of the lightening according to the clinical doctors’ actual demand.
• Four different filters can be inserted into the illumination pathway. Anti-ultraciolet radiation filter ensures patients’ safety during examination.
| Xcel255 | Xcel400/Xcel700 | |
Microscope | Galilean | Galilean |
Magnification Change | 3 step rotation | 3 step rotation (5 step*) |
Eyepiece | 12.5x | 12.5x |
Magnification Ratio | 10x, 16x, 25x | 10x, 16x, 25x (6x, 40x*) |
PD Range | 48.5 - 80 mm | 48.5 - 80 mm |
Dioptric Adjustment | ±5 | ±6 |
Slit Width | 0 - 13.5mm | 0 - 12 mm |
Slit Length | 0 - 13.5 mm | 0 - 12 mm |
Slit Apertures | 0.6, 5.8, 9, 13.5 mm | 0.3, 1, 3, 5, 9, 12 mm |
Slit Rotation | 0 - 180° | 0 - 180° |
Filters | Red free, cobalt blue heat absorbing | Red free, cobalt blue, heat absorbing, neutral density |
Movement Ranges: | ||
Longitudinal (in/out) | 90 mm | 90 mm |
Lateral (left/right) | 107 mm | 100mm |
Vertical (up/down) | 30 mm | 30 mm |
Chin Rest Range | 80mm | 80mm |
Illumination | 6V 20W halogen | 6V 20W halogen |
Voltage | 90 - 250 VAC | 110/220 VAC |
Frequency | 50/60 Hz | 50/60 Hz |
Table Base Dimensions | 465 x 316 mm | 465 x 316 mm |
Weight (packed) | 52 lbs. (23.64 kg) | 52 lbs. (23.64 kg) |
