Features :
• The Galilean-type magnification system provides the 10X, 16X and 25X three magnification(standard configuration) and 6X, 10X, 16X, 25X and 40X (professional configuration); there is no need to change the eyepieces.
• The CCD adaptor, digital camera and teaching tube are supported.
• It can provide with 0.5mm, 3.5mm, 8mm and 14mm (max) apertures; it is specially fit for the examination for contact lens and foreign body in cornea.
• The German imported Osram 12V30W halogen lamp and LED lamp are both available.
• The slit angle can turn over 180 degree, horizontal scanning is supported.
• Thermal safety, cobalt blue and red free filters are provided.
Microscope type | Galilean-Type | Magnification | SL-280S:3-STEP |
SL-280: 5-STEP | |||
Eye piece | 12.5× | Total magnification Ratio | 10×, 16×, 25× (standard configuration) 6×,10×, 16×, 25×,40× (professional configuration) |
Range of pupil distance | 55mm~78mm | Field of view | 40× (Ø5.5mm), 25× (Ø8.5mm), 16× (Ø13.5mm), 10×(Ø22mm), 6× (Ø34.7mm) |
Slit width | 0 ~14mm adjustable | Adjustment of diopter | ±6D |
Slit angle | 0º~180º | Slit height | 1~14mm adjustable |
Light spot diamater | φ14mm,φ8mm, φ3.5mm,φ0.5mm | Filter | Thermal safety,Red-free,Cobalt Blue |
Illumination bulb | 12V/30W Halogen Lamp | Dimension | 740 x 450 x 500(mm) |
Power | 220V/110V~±10% |
