| Microscope | Microscope type | Converging stereoscope microscope |
| Magnifications selection | Two steps magnifications | |
| Eyepiece | 10X | |
| Magnification ratio(field of view) | 10X(18mm), 16x(14.5mm) | |
| Pupillary adjustment | 50mm-82mm | |
| Diopter adjustment | -5D to +5D | |
| Base | Side shift | 110mm |
| Depth shift | 90mm | |
| Height shift | 30mm | |
| Chin rest | Height shift | 80mm |
| Fixation target | Red LED | |
| Illumination System | slit width | 0-9mm continuous(at 10mm, slit becomes circle) |
| slit height | 1-8mm continuous | |
| slit angle diameter of light spot | 0°~ 180° continuous | |
| Filter | Heat absorption ,Grey ,Red-free ,Cobalt Blue | |
| Illumination Bulb | 12V 50W halogen lamp | |
| Power | Input Voltage | 110V/220V/AC |
| Frenquency | 50/60Hz | |
| Power Consumption | 68VA | |
| Weight and size | Gross weight | 18kg |
| Dimension | 690*440*420mm(L*W*H) |
