Specifications
Display size: | 15 inch LCD screen |
| Working frequency: | 2.0MHz~10MHz |
| Display mode: | B, B+B, B+M, M, 4B |
| Scanning range: | Convex array 60°~150° |
| Amplification factor： | 1.0, 1.2, 1.5,2.0 |
| Gain control: | 8 segments TGC and overall gain can be adjusted respectively |
| Image processing: | 8 γ corrections, frame correlation, point correlation, line correlation, digital filtering, digital edge enhancement and pseudo color processing, etc |
| Image gray-scale: | 256 levels |
| Scanning line number: | 512 lines/frame |
| Frame rate: | 30 frames/second |
| Digital scanning conversion: | 512×512×8 bits |
| Memory: | USB flash disk large volume image storage |
| Conventional measurements: | distance, perimeter, area, volume |
| Obstetric measurement: | gestational weeks (BPD, GS, CRL, FL, HL, OFD, TTD, AC), expected date of confinement and fetus weight, etc. |
| Report function: | auto make report |
| Built-in battery capacity: | can work more than 5 hours |
| Output interface: | USB port, video. |
| Overall size: | 362mm×340mm×60mm |
| Total weight: | 4Kg(with battery) |
